22kW 27.5kVA Diesel Generator, 50Hz, Cummins Powered, 3 Phase
Key Specifications / Features
Model no.: GGS-240312-DGS-03
hits: 0
Introducing the 22kW Diesel Generator, delivering prime power of 22kW (27.5kVA) with reliability and efficiency. Powered by Cummins, it operates at 50Hz, ensuring consistent performance. With a robust 4-cylinder, 4-stroke engine and a rated voltage of 230V and 400V, it's suitable for various applications. Featuring a 3-phase, 4-wire setup, it offers seamless integration into diverse electrical systems. Trust in this generator to provide dependable power whenever and wherever it's needed.
Request a quote
Tags
Detail Information
Product Name: 22kW 27.5kVA Diesel Generator
Model: GGS-27.5-C
Engine Brand: Cummins
Frequency: 50Hz
Prime Power: 22kW, 27.5kVA
Rated Voltage: 230V, 400V
Rated Current: 39A
Engine Type: 4 Cylinder, 4 Stroke
Alternator Type: Self-Excited, 3 Phase & 4 Wire
Dimension (L x W x H): 1860 x 750 x 1350 mm
Technical Data
| Generator Specification | |
| Generator Model | GGS-27.5-C |
| Frequency | 50Hz |
| Prime Power | 22kW/27.5kVA |
| Standby Power | 24.2kW/31kVA |
| Standard Voltage | 230V/400V |
| Rated Current | 39A |
| Dimension (L x W x H) | 1860 x 750 x 1350 mm |
| Weight | 700 kg |
| Engine Specification | |
| Engine Brand | Cummins |
| Model | 4B3.9-G2 |
| Induction System | Natural Air Intake |
| Number of Cylinders | 4 Cylinder, Vertical In-Line |
| Cycle | 4 Stroke |
| Starting Method | Electric Start |
| Displacement | 3.9 L |
| Bore x Stroke | 102 x 120 mm |
| Compression Ratio | 18.0:1 |
| Rated Speed | 1500rpm |
| Governor Type | Electronic |
| Alternator Specification | |
| Exciter Type | Self-excited |
| Wiring Type | 3 Phase & 4 Wire |
| Power Factor | 0.8 |
| Protection Grade | IP23 |
| Insulation Grade | Class H |
