20kW 25kVA Diesel Generator, 50Hz, Cummins Engine, 4 Stroke
Key Specifications / Features
Model no.: GGS-240312-DGS-04
Hits: 4
Introducing the 20kW Diesel Generator, engineered for prime power applications. With a robust Cummins engine, it delivers 20kW prime power (25kVA) at 50Hz. Featuring water cooling and a brushless, self-excited alternator, it ensures reliable performance. Rated at both 230V and 400V, it offers versatility for various electrical needs. Trust in this generator for dependable power generation in diverse settings.
Request a quote
Tags
Detail Information
Product Name: 20kW 25kVA Diesel Generator
Model: GGS-25-C
Engine Brand: Cummins
Frequency: 50Hz
Prime Power: 20kW, 25kVA
Rated Voltage: 230V, 400V
Cooling Method: Water Cooled
Engine Type: 4 Cylinder, 4 Stroke
Alternator Type: Brushless, Self-Excited, 3 Phase & 4 Wire
Dimension (L x W x H): 1860 x 750 x 1350 mm
Technical Data
| Generator Specification | |
| Generator Model | GGS-25-C |
| Frequency | 50Hz |
| Prime Power | 20kW/25kVA |
| Standby Power | 22kW/27.5kVA |
| Standard Voltage | 230V/400V |
| Dimension (L x W x H) | 1700 x 925 x 1470 mm |
| Weight | 740 kg |
| Engine Specification | |
| Engine Brand | Cummins |
| Model | 4B3.9-G1 |
| Aspiration: | Natural |
| Number of Cylinders | 4 Cylinder In Line |
| Cycle | 4 Stroke |
| Starting Method | Electric Start |
| Displacement | 3.9 L |
| Bore x Stroke | 102 x 120 mm |
| Rated Speed | 1500rpm |
| Compression Radio | 16.6:1 |
| Governor Type | Electronic |
| Alternator Specification | |
| Alternator Model | Stamford PI144E |
| Exciter Type | Self-excited, Brushless |
| Wiring Type | 3 Phase & 4 Wire |
| Cooling Method | Water Cooled |
| Power Factor | 0.8 |
| Protection Grade | IP23 |
| Insulation Grade | Class H |
