3 Phase Diesel Generator, 12kW 15kVA, 50Hz, Perkins Engine
Key Specifications / Features
Model No.: GGS-240311-DGS-03
Hits: 18
Introducing the 3 Phase Diesel Generator, featuring a Perkins engine for reliability. Operating at 50Hz, it delivers 12kW power (15kVA) with a voltage of 400/230V. This water-cooled generator is equipped with a durable 3-cylinder, 4-stroke engine and a brushless, self-excited alternator. Its 3-phase, 4-wire setup ensures compatibility across various applications, making it an ideal choice for both residential and commercial use.
Request a quote
Tags
Detail Information
Product Name: 3 Phase Diesel Generator
Model: GGS-15-P
Engine Brand: Perkins
Frequency: 50Hz
Prime Power: 12kW / 15kVA
Rated Voltage: 400/230V
Rated Current: 21.6A
Engine Type: Water Cooled, 3 Cylinder, 4 Stroke
Alternator Type: Brushless, Self-Excited, 3 Phase & 4 Wire
Net Weight: 695 KG
Dimension (L x W x H): 1900 x 860 x 1020 mm
Technical Data
| Generator Specification | |
| Generator Model | GGS-15-P |
| Frequency | 50Hz |
| Prime Power | 12kW/15kVA |
| Standby Power | 13kW/17kVA |
| Rated Voltage | 400/230V |
| Rated Current | 21.6A |
| Type | Silent |
| Dimension (L x W x H) (mm) | 1900 x 860 x 1020 |
| Net Weight (KG) | 695 |
| Engine Specification | |
| Engine Brand | Perkins |
| Model | 403A-15G2 |
| Cooling System | Water Cooled |
| Aspiration | Natural Aspiration |
| Fuel System | Direct Inject |
| Number of Cylinders | 3 Cylinder In Line |
| Cycle | 4 Stroke |
| Starting Method | Electric Start |
| Displacement | 1.496 L |
| Bore x Stroke | 84 x 90 mm |
| Compression Ratio | 22.5:1 |
| Rated Speed | 1500rpm |
| Rated Power (With Fan) | 13.7kW |
| Governor Type | Mechanical |
| Alternator Specification | |
| Alternator Brand | Stamford PI044G |
| Exciter Type | Brushless, Self-Excitation |
| Phase | 3 |
| Voltage | 400/230V |
| Wiring Type | 3 Phase & 4 Wire, Y Type |
| Power Factor | 0.8 |
| Prime Power | 12 kW |
| Protection Grade | IP23 |
| Insulation Grade | Class H |
