48kW 60kVA Diesel Generator, 50Hz, Cummins Engine, 4 Cylinder
Key Specifications / Features
Model No.: GGS-240312-DGS-07
Hits: 3
Introducing the 48kW Diesel Generator, a reliable power solution with a Cummins engine at its core. Operating at 50Hz, it delivers a prime power of 48kW (60kVA) with a 3-phase, 4-wire configuration. Featuring a robust 4-cylinder, 4-stroke engine and a brushless, self-excited alternator, this generator ensures efficient and dependable power generation. Trust in its performance for a wide range of applications, providing consistent electricity whenever and wherever needed.
Request a quote
Tags
Detail Information
Product Name: 48kW 60kVA Diesel Generator
Model: GGS-60-C
Engine Brand: Cummins
Frequency: 50Hz
Prime Power: 48kW, 60kVA
Rated Voltage: 230V, 400V
Rated Current: 95A
Cooling Method: Water Cooled
Engine Type: 4 Cylinder, 4 Stroke
Alternator Type: Brushless, Self-Excited, 3 Phase 4 Wire
Dimension (L x W x H): 2300 x 960 x 1400 mm
Technical Data
| Generator Specification | |
| Generator Model | GGS-60-C |
| Frequency | 50Hz |
| Prime Power | 48kW/60kVA |
| Standby Power | 53kW/66kVA |
| Rated Voltage | 230V, 400V |
| Rated Current | 95A |
| Dimension (L x W x H) (mm) | 2300 x 960 x 1400 |
| Net Weight (KG) | 1150 |
| Engine Specification | |
| Engine Brand | Cummins |
| Model | 4BTA3.9-G2 |
| Cooling System | Water Cooled |
| Aspiration | Turbocharged |
| Fuel System | BYC A/Electronic Governor |
| Number of Cylinders | 4 Cylinder In Line |
| Cycle | 4 Stroke |
| Starting Method | Electric Start |
| Displacement | 3.9 L |
| Bore x Stroke | 102 x 120 mm |
| Compression Ratio | 17.3:1 |
| Rated Speed | 1500rpm |
| Rated Power (With Fan) | 58kW |
| Governor Type | Electrical |
| Alternator Specification | |
| Alternator Brand | Stamford UCI224E |
| Exciter Type | Brushless, Self-Excitation |
| Wiring Type | 3 Phase 4 Wire, Y Type |
| Power Factor | 0.8 |
| Protection Grade | IP23 |
| Insulation Grade | Class H |
