13kW 16kVA Diesel Generator, Perkins 403D-15G, 3 Phase, 60Hz
Key Specifications / Features
Model no.: GGS-240328-DGS-05
Hits: 0
Presenting our robust 3-phase diesel generator designed for 60Hz applications, delivering a reliable power output of 13kW and 16kVA. Featuring a dependable 3-cylinder Perkins 403D-15G engine and coupled with a Stamford PI044G alternator, this generator ensures efficient performance. With a water-cooled system and mechanical governor, it offers durability and stability for various industrial and commercial needs.
Request a quote
Tags
Detail Information
Product Name: 13kW 16kVA Diesel Generator
Model: GGS-16-P
Frequency: 60Hz
Prime Power: 13kW, 16kVA
Standby Power: 14kW, 18kVA
Rated Voltage: 127V, 220V
Displacement: 1.496 L
Bore x Stroke: 84 x 90 mm
Compression Ratio: 22.5:1
Engine: Perkins 403D-15G, 4 Stroke, 3 Cylinder in Line
Alternator: Stamford PI044G, Brushless, Self-excited
Other Feature: 3 Phase, Water Cooled, Mechanical Governor
Technical Data
| Generator Specification | |
| Generator Model | GGS-16-P |
| Frequency | 60Hz |
| Prime Power | 13kW/16kVA |
| Standby Power | 14kW/18kVA |
| Rated Voltage | 127/220V |
| Dimension (L x W x H) (mm) | 1400 x 750 x 1120 |
| Gross Weight (KG) | 430 |
| Engine Specification | |
| Engine Brand | Perkins |
| Engine Model | 403D-15G |
| Cooling System | Water Cooled |
| Aspiration | Naturally Aspirated |
| Number of Cylinders | 3 Cylinder Vertical in Line |
| Cycle | 4 Stroke |
| Displacement | 1.496 L |
| Bore x Stroke | 84 x 90 mm |
| Compression Ratio | 22.5:1 |
| Rated Speed | 1800 RPM |
| Governor type | Mechanical |
| Alternator Specification | |
| Alternator Brand | Stamford |
| Alternator Model | PI044G |
| Excitation system | Brushless, Self-excited |
| Number of phase | 3 Phase |
| Power Factor | 0.8 |
| Protection Grade | IP23 |
| Insulation Class | H |
