460kW Diesel Generator, Cummins KTAA19-G6, 50Hz, Water Cooled
Key Specifications / Features
Model No.: GGS-240328-DGS-17
Hits: 16
Presenting our dynamic 50Hz diesel generator, featuring a prime power output of 460kW and 575kVA. Driven by the renowned Cummins KTAA19-G6 engine and paired with a Stamford HCI544E alternator, this generator ensures reliable performance for your power needs.
Request a quote
Tags
Detail Information
Product Name: 460kW Diesel Generator
Model: GGS-575-C
Frequency: 50Hz
Prime Power: 460kW, 575kVA
Standby Power: 506kW, 633kVA
Rated Voltage: 230, 400V
Displacement: 19 L
Bore x Stroke: 159 x 159 mm
Compression Ratio: 13.9:1
Engine: Cummins KTAA19-G6, 4 Stroke, 6 Cylinder
Alternator: Stamford HCI544E, Brushless, Self-excited
Other Feature: 3 Phase, Water Cooled, Mechanical Governor
Technical Data
| Generator Specification | |
| Generator Model | GGS-575-C |
| Frequency | 50Hz |
| Prime Power | 460kW/575kVA |
| Standby Power | 506kW/633kVA |
| Rated Voltage | 230/400V |
| Dimension (L x W x H) (mm) | 3470 x 1550 x 2200 |
| Gross Weight (KG) | 4350 |
| Engine Specification | |
| Engine Brand | Cummins |
| Engine Model | KTAA19-G6 |
| Cooling System | Water Cooled |
| Aspiration | Turbocharged and Air-to-air Cooled |
| Number of Cylinders | 6 Cylinder in Line |
| Cycle | 4 Stroke |
| Displacement | 19 L |
| Bore x Stroke | 159 x 159 mm |
| Compression Ratio | 13.9:1 |
| Rated Speed | 1500 RPM |
| Governor type | Mechanical |
| Alternator Specification | |
| Alternator Brand | Stamford |
| Alternator Model | HCI544E |
| Excitation system | Brushless, Self-excited |
| Number of phase | 3 Phase |
| Power Factor | 0.8 |
| Protection Grade | IP23 |
| Insulation Class | H |
