How to Resolve Insufficient Cylinder Pressure in Diesel Generator


The reliability and efficiency of diesel generators are essential for a consistent and stable power supply. However, when a failure of insufficient cylinder pressure occurs, it may affect its normal operation and reduce its performance. This article will describe detailed steps and methods to diagnose and resolve the problem of insufficient cylinder pressure in diesel generators, helping to ensure the efficient operation of generators in a variety of operating conditions.

Symptoms of Insufficient Cylinder Pressure


Symptoms of inadequate cylinder compression include easy crankshaft rotation without decompression, difficulty starting especially in winter, unstable generator operation with unclear, inefficient sound, decreased power output, blue smoke from exhaust, increased fuel and oil consumption, elevated water temperature, and overheating of exhaust pipes. Common causes include improper valve closure, cylinder head gasket leaks, piston ring leaks, and injector mounting leaks.

Diagnosing Insufficient Cylinder Pressure


Diagnosing insufficient cylinder pressure in diesel generators typically involves the following steps and checks to ensure stable operation and effective power output.

1. Check Injector Nozzle Heat Shield and Sealing Copper Gasket


Begin by inspecting the injector nozzle heat shield for damage or burning, and ensure the sealing copper gasket is intact. Damage to the heat shield or leakage from the copper gasket can cause pressure loss in the combustion chamber, affecting cylinder pressure output. If damage is found, promptly replace the heat shield or sealing copper gasket, and reconfirm cylinder pressure to ensure proper engine startup.

2. Inspect Intake and Exhaust Valves and Valve Seats


Next, check for excessive wear in intake and exhaust valves and valve seats, which can result in inadequate valve sealing. Verify the smoothness of the valve face against the cylinder head surface and check for noticeable gaps between the valve and valve seat. If significant wear is detected, replace the affected valves and valve seats to restore proper sealing.

3. Assess Piston Ring Condition


Further, examine piston rings for signs of burning, sticking, or loss of elasticity, which can compromise sealing between the piston and cylinder wall, leading to compressed gas leakage. Pay particular attention to ring alignment and correct installation to ensure effective sealing of the combustion chamber for ignition. If issues are identified, replace the piston rings and clean carbon deposits from ring grooves to ensure proper positioning in the piston combustion chamber and maintain sealing.

4. Address Piston and Groove Wear


If there is excessive wear in the piston and its grooves, often due to friction between the piston and connecting rod, it can lead to severe wear of piston rings and groove sealing performance. In such cases, replace the piston rings promptly to prevent further cylinder pressure loss.

5. Check Cylinder Wall Wear


Finally, inspect the generator's cylinder walls for scratches or scoring caused by piston ring sticking, fracture, or excessive wear. Prolonged operation and friction can wear down cylinder walls, affecting cylinder sealing performance. If significant scratches or grooves are found, replace the entire cylinder to restore proper sealing effectiveness.

By following these detailed steps and methods, various potential causes of insufficient cylinder pressure in diesel generators can be effectively identified and addressed, ensuring stable power output. Regular maintenance and inspection are key to preserving generator performance and reliability, essential for addressing diverse challenges and operating environments. Ensuring adequate cylinder pressure not only protects equipment but also safeguards stability in power supply.
